5" Channel Carhauler (C5)

Available Lengths

  • 10’
  • 12’
  • 14’
  • 16’
  • 18’
  • 20’
  • 22’

Dare to Compare

Dare To Compare

Financing

Financing

Standard Features

  • 9” x 33” Treadplate Removable Alum Fenders
  • 5’ Channel Ramps w/ Holder
  • 5” Channel Frame & Tongue
  • 3” Channel Crossmembers 24” on Center
  • 2” Treated Pine Lumber Deck
  • 83” Wide Deck (Except with Drop Axles)
  • DOT Approved Flushmount Lifetime LED Lights
  • Sealed Wire Harness
  • Sand Blasted, Acid Washed, Powder Coated
  • GN Option Equipped with 2 Jacks
  • GN Equipped w/Lockable Front Toolbox
  • 5 year Dexter Axle Warranty

Notes:
Trailer will have 80” Frame with 3500 # Torsion Axle
Bumperpull Tongue Length (3’ 5”)


Estimated Weights

Length Axles Est. Base Weight
14' 2 x 3,500 lbs 1,740 lbs / 789 kg
16' 2 x 3,500 lbs 1,850 lbs / 839 kg
18' 2 x 3,500 lbs 1,970 lbs / 894 kg
20' 2 x 3,500 lbs 2,080 lbs / 943 kg
† Weights are estimated for base trailer only. We make no guarantee regarding the accuracy of estimated weights.

Options

Default options, those included in the base model, are marked by a check .

Coupler Options

[2] BP 2” A-Frame
[A] BP 2 5/16” A-Frame
[D] BP 2” Adjustable
[J] BP 2 5/16” Adjustable (14,000 lb.)
[M] BP 2” Atwood Style A-Frame Coupler
[N] BP 2 5/16” Atwood Style A-Frame Coupler
[P] 3” Pintle Eye - Channel-mount (14,000 lb.)
[R] GN 2 5/16” Round (25,000 lb.) w/ Toolbox

Axle Options

[32CD] (2) 3,500# (Dexter) One Electric (Drop Axle)
[32CS] (2) 3,500# (Dexter) One Electric (Spring)
[32CT] (2) 3,500# (Dexter) One Electric (Torsion)
[32DS] (2) 3,500# (Dexter) Idler (Spring)
[32ED] (2) 3,500# (Dexter) Electric (Drop Axle)
[32ES] (2) 3,500# (Dexter) Electric (Spring)
[32ET] (2) 3,500# (Dexter) Electric (Torsion)
[32MS] (2) 3,500# (Dexter) Surge Hyd. Drum [Surge Coupler] 1 Brake 1 Drag (Spring)
[32SS] (2) 3,500# (Dexter) Surge Hydraulic Drum [Surge Coupler] (Spring)

Tail Options

[S] Straight Deck w/ 5’ Slide-in Ramps
[2] 2’ Dovetail w/ 5’ Slide-in Ramps
[4] 4’ Dovetail w/ 5’ Slide-in Ramps
[A] 2’ Dovetail w/ 2 Fold-up Ramps
[B] Straight Deck w/ 4’ Split Heavy Duty Gate
[C] Straight Deck w/ 2 Fold-up Ramps
[D] 4’ Dovetail w/ 2 Fold-up Ramps
[E] 2’ Dovetail w/ 3 Fold-up Ramps
[F] Straight Deck w/ Fold In Gate
[G] Straight Deck w/ 4’ Fold-up Gate
[H] Straight Deck w/ 4’ Heavy Duty Fold-up Gate
[J] 2’ Dovetail w/ 4’ Heavy Duty Fold-up Gate
[K] 2’ Dovetail w/ Split Heavy Duty Gate
[M] 4’ Dovetail w/ Split Heavy Duty Gate
[N] 2’ Dovetail w/ 5’ Rear Slide-in Ramps
[P] 4’ Dovetail w/ 5’ Rear Slide-in Ramps
[R] Straight Deck w/ Rear Slide-in Ramps

Color Options

[K] Black Powder Coat
[0] Primer + Black Powder Coat (Texas Only)
[1] Primer + Red Powder Coat (Texas Only)
[2] Primer + Tractor Green Powder Coat (Texas Only)
[3] Primer + White Powder Coat (Texas Only)
[4] Primer + Equipment Yellow Powder Coat (Texas Only)
[5] Primer + Tractor Orange Powder Coat (Texas only)
[6] Primer + Grey Powder Coat (Texas only)
[8] Primer + Desert Tan Powder Coat (Texas Only)
[G] Grey Powder Coat
[J] Tractor Green Powder Coat
[N] Tractor Orange Powder Coat
[P] Primer Only (Texas Only)
[R] Red Powder Coat
[T] Desert Tan Powder Coat
[W] White Powder Coat
[Y] Equipment Yellow Powder Coat (Texas & Ohio Only)
[Z] No Paint No Primer (Texas Only)

Other Options

[-BWFL] Blackwood Classic Full Deck
[-BWOT] Blackwood Classic Outer Deck
[-DL01] 1 Pair of Flushmount D-Rings on Wood Floor
[-DM01] 1 Extra Pair Flushmount D-Rings on Steel Floor
[-DR01] 1 Pair D-Rings
[-RT01] Rate at 9900 GVWR
[-TB01] Front Toolbox (with 7k Jack)
[0] Cold Weather Wiring Harness (Paris Only)
[2] Upgrade to 225/75 R15 on 3.5k Axles
[3] 10k Jack (Bumper Pull)
[4] Plate for Winch
[7] Upgrade to 7k Jack
[8] 2 Stake Pockets In Front of Trailer
[9] 4ft Expanded Metal Sides (Removable)
[A] Side Mount ATV Ramps (12ft or Longer)
[B] 12”oc Crossmembers
[C] 4ft Solid Metal Sides (Removable)
[E] Rough Oak Floor (Paris and Ohio Only)
[F] Steel Diamond Plate Fenders
[G] 4ft Side Gate (14ft or longer)
[H] Landscape Toolbox (must have 2ft or 4ft Sides)
[K] Expanded Metal Chain Tray
[M] Open Pit Steel Floor w/4 Flushmount D-Rings
[N] Diamond Plate Running Boards (Paris ONLY)
[P] 2” Pipetop Siderails (Removable)
[Q] Rubrail
[R] U8 Side Rail (Removable)
[S] 11ga(1/8”) DP Steel Floor w/ 4 Flushmount D-Rings & 16”oc
[T] Mount Only for Spare Tire
[U] Rear Trailer Support Jacks
[V] Spare Tire and Mount
[X] 16”oc Crossmembers
[Z] 22” Solid Metal Sides w/ 2” pipe-top (Removable)

Parts Guide

Model Part Description Category Part Number
C5 3,500# Electric / Spring
(Axle Brake 3555OE-ST-EZ 95x80)
AXLE 110103
C5 3,500# Idler / Spring
(Axle Idler 35550I-ST-EZ 95x80)
AXLE 110104
C5 Reflector Tape, Conspicuity R&W BODY 170237
C5 Coupler, 2” A-Frame Bulldog COUPLER 140200
C5 Fender Tandem 9x72 Alum DP - 15”
(3500 lb axle)
FENDER 160601
C5 Fender Tandem 9x72 Alum DP - 16”
(5200 lb axle)
FENDER 160602
C5 Bracket Weld-on 5/16” Safety Chain HARDWARE 180410
C5 Jack, 5K Pipe Mount 15” Topwind JACK 140100
C5 Rear Support Jack
(Option)
JACK 140100
C5 Ramp 3” Chnl 13”x60” C5&C6 -Semin
(Slide-in Ramps)
RAMPS 160273
C5 Bolt Equal’r 7/8”x4.75” Slipper 7K
(with 5.2k axles)
SUSPENSION 120119
C5 Bolt, Hanger 9/16x3.5” Slipper 7K
(with 5.2k axles)
SUSPENSION 120118
C5 Equalizer 3.5K Triangle Double Eye
(3500 lb axles)
SUSPENSION 120217
C5 Equalizer 7K  QRG (12”)
(5200 lb axles)
SUSPENSION 120216
C5 Hanger 2-Axle 3.5K, Frt, Ctr, Rear SUSPENSION 120145
C5 Hanger Bolt 3”x9/16” - 18 SUSPENSION 120141
C5 Hanger Center 7K Slipper
(5200 lb axles)
SUSPENSION 120115
C5 Hanger Front 7K Slipper
(5200 lb axles)
SUSPENSION 120116
C5 Hanger Kit 2-Axle Dbl  Eye 3.5 -52K SUSPENSION 120110
C5 Hanger Kt Tandem Axle Slipper 52/7k SUSPENSION 120112
C5 Hanger Kt Tandem Axle Slipper 52/7k
(5200 lb axles)
SUSPENSION 120112
C5 Hanger Rear 7K Slipper
(5200 lb axles)
SUSPENSION 120117
C5 Lock Nut for 7K Eq Bolt 7/8”
(with 5.2k axles)
SUSPENSION 120218
C5 Lock Nut for hanger bolt 9/16” SUSPENSION 120311
C5 Spring Dbl.eye 4 leaf 1750# SUSPENSION 120100
C5 U-Bolt Kit 2-3/8” Round (for 3.5k)
(3500 lb axles)
SUSPENSION 120300
C5 U-Bolt Kit 3” Rd. for 5.2-7K
(5200 lb axles)
SUSPENSION 120301
C5 Tire ST205/75R15 Radial LR-C TIRE 130101
C5 15” white spoke Wheels w/ 5 on 5”
(3500 lb axle)
TIRES & WHEELS 130300
C5 Tire&Whl 205/75R15 on 550 white spk
(3500 lb axle)
TIRES & WHEELS 130200

Parts Guide Disclaimer: Parts can change based on the options, production date, and production location of the trailer. If there is any doubt about parts fitment please contact a PJ Parts representative with the VIN of the trailer in question.
