Single Axle HD Tilt (T1)

Available Lengths

  • 13’
  • 16’

Dare to Compare

Dare To Compare

Financing

Financing

Standard Features

  • 7,000 lb. G.V.W.R.
  • 7,000 lb. x 1 G.A.W.R.
  • 2” Ball Adjustable Bulldog Coupler
  • Safety Chains
  • 1 - Drop Leg Jack (8,000 lb.)
  • 1 - Dexter E- Z lube Brake Drop Axle (7,000 lb)
  • 2 - 16” White Spoke Wheels
  • 2 - 235/80R16 Radial Tires (3,520 lb)
  • Stake Pockets
  • Electric Breakaway Kit w/ Charger
  • Removable Tread-plate Steel Fenders
  • Expanded Metal Tool Tray In Tongue
  • 11 Degree Tilt Angle
  • Hydraulic Cushion Cylinder w/ Reservoir
  • 5” Channel Tongue
  • 5” x 2” Steel Tube Frame
  • 3” Channel Crossmembers 16” on Center
  • 2” Treated Pine Lumber Deck
  • 81” x 13’ Tilting Deck
  • 81” Between Fenders
  • DOT Approved Flushmount Lifetime LED Lights
  • Sealed Bargman Wire Harness w/ 7-Way RV Plug
  • Sand Blasted, Acid Washed, Powder Coated
  • Knife Edge Tail
  • 4 Recessed D-rings & 1 Center D-ring
  • Bull Nose Bumper
  • Mitered Front Corners
  • 5 year Dexter Axle Warranty

Notes:
Bumper-pull Tongue Length (5’)

Options

Default options, those included in the base model, are marked by a check .

Coupler Options

[D] BP 2” Adjustable
[J] BP 2 5/16” Adjustable
[P] 3” Pintle Eye - Channel-mount (14,000 lb.)

Axle Options

[51BD] (1) 5,200# (Dexter) Electric (Drop Axle)
[71BD] (1) 7,000# (Dexter) Electric (Drop Axle)
[71SD] (1) 7,000# (Dexter) Surge Hydraulic Drum [Surge Coupler] (Drop Axle)
[91BD] (1) 7,000# w/235/85R16 LR-G Tires (Dexter) Electric (Drop Axle)
[91SD] (1) 7,000# w/235/85R16 LR-G Tires (Dexter) Surge Hydraulic Drum [Surge Coupler] (Drop Axle)

Tail Options

[T] Tilt Deck

Color Options

[K] Black Powder Coat
[0] Primer + Black Powder Coat
[1] Primer + Red Powder Coat
[2] Primer + Tractor Green Powder Coat
[3] Primer + White Powder Coat
[4] Primer + Equipment Yellow Powder Coat
[5] Primer + Tractor Orange Powder Coat
[6] Primer + Grey Powder Coat
[8] Primer + Desert Tan Powder Coat
[G] Grey Powder Coat
[J] Tractor Green Powder Coat
[N] Tractor Orange Powder Coat
[P] Primer Only
[R] Red Powder Coat
[T] Desert Tan Powder Coat
[W] White Powder Coat
[Y] Equipment Yellow Powder Coat
[Z] No Paint No Primer

Other Options

[-BWFL] Blackwood Classic Full Deck
[-BWOT] Blackwood Classic Outer Deck
[-DL01] 1 Pair of Flushmount D-Rings on Wood Floor
[-DM01] 1 Extra Pair Flushmount D-Rings on Steel Floor
[-DR01] 1 Pair D-Rings
[-DR07] 7 Pair D-Rings
[-FE05] Weld on Fenders
[-RT01] 1 Pair Weld-On Strap Ratchets
[-TB02] Bumper Pull Double Deck Toolbox (Upgrade)
[-TB04] Full Size Divided Toolbox Upgrade (BP Only)
[-TRA1] 1/2 x 1/2 Square Traction Bars on Rear of Deck
[-WN08] Warn 8k Zeon Winch w/Plate & Battery
[-WN95] SuperWinch TS9500 w/Plate & Battery
[-WP03] Winch Plate w/ Welded Receiver Hitch
[0] Cold Weather Wiring Harness (7-Way RV)
[3] Upgrade to Single 10k Jack (Bumper Pull)
[4] Plate for Winch
[7] Douglas Fir Lumber
[B] Solar Battery Charger
[C] 12”oc Crossmembers
[E] Rough Oak Floor
[H] Power up Power down Tilt
[K] Power Up/Down & Gravity Down
[M] Mount Only for Spare Tire
[P] 11ga(1/8”)DP Steel Floor w/ 4 Flushmount D-Rings & 16”oc
[Q] Front Toolbox (Bumper Pull & Pintle)
[R] Expanded Metal Traction Plate on Tailboard
[T] Spare Tire and Mount (Bumper Pull)
[Y] 1x1 Angle Traction Bars on Rear of Deck
[Z] Roller on Front of Deck for Winch Cable

Parts Guide

Model Part Description Category Part Number
T1 Dexter Axle Electric 70685e-4D-EZ 95 x 78 AXLE ASSEMBLIES 110194
T1 Clevis for Linkage on Tilt latch BODY 180127
T1 Linkage Rod on Tilt Latch 7”x1/2” BODY 180128
T1 Reflector Tape, Conspicuity R&W BODY 170237
T1 Hub Drum Brk 12K QRG 5/8” stud flat BRAKE 111208
T1 Bracket Weld-on 5/16” Safety Chain HARDWARE 180410
T1 Valve, 3-way, Diverting Ball HARDWARE 190109
T1 Oil Reservoir HYDRAULIC 190304
T1 Jack, 7K Dropleg Square Topwind JACK 140101
T1 Coupler, 7k 2” Adjustable Height JACKS & COUPLERS 140222
T1 Tilt Trlr Tailight Bracket Straight LIGHTING 170125
T1 16” White Spoke Wheels w/ 8 on 6.5”
(7000 lb axle)
TIRES & WHEELS 130303

Parts Guide Disclaimer: Parts can change based on the options, production date, and production location of the trailer. If there is any doubt about parts fitment please contact a PJ Parts representative with the VIN of the trailer in question.
