72" Tandem Axle Dump (D3)

D3 Trailer

Resources

Media


Available Lengths

  • 10’
  • 12’

Dare to Compare

Dare To Compare

Financing

Financing

Standard Features

  • 9,900 lb. G.V.W.R.
  • 5,200 lb. x 2 G.A.W.R.
  • 2 5/16” A Frame Coupler
  • Safety Chains
  • 1 - Drop Leg Jack (7,000 lb.)
  • 2 - Dexter E- Z lube Brake Axle (5,200 lb.)
  • 6 Leaf Slipper Spring Suspension
  • 4 - 15” White Spoke Wheels
  • 4 - 225/75R15 Radial Tires ( lb.)
  • Electric Breakaway Kit w/ Charger
  • DOT Reflective Tape
  • Treadplate Steel Fenders
  • Toolbox
  • Barn Door Gate
  • 40° Dump Pitch
  • 12VDC Hydraulic Pump
  • 5” x 30” Hyd. Cylinder
  • 12’ Control Cable
  • 5” Channel Main Frame & Tongue
  • 16” On Center 3” Channel Crossmembers
  • 10ga. Steel Bed
  • 72” Wide Bed
  • 20” 10ga Steel Sides
  • DOT Approved Flushmount Lifetime LED Lights
  • Sealed Wire Harness w/ 7-Way RV Plug
  • Sand Blasted, Acid Washed, Powder Coated
  • Interstate (TM) Deep Cycle Battery
  • 110V Integrated Trickle Charger
  • 5 year Dexter Axle Warranty

Estimated Weights
Length Axles Est. Base Weight †
10' 2 x 5,200 lbs 2,520 lbs / 1,143 kg
12' 2 x 5,200 lbs 3,020 lbs / 1,370 kg
† Weights are estimated for base trailer only. We make no guarantee regarding the accuracy of estimated weights.

Options

Default options, those included in the base model, are marked by a check .

Coupler Options
[A] BP 2 5/16” A-Frame (12,500lb.)
[D] BP 2 5/16” Adjustable (14,000 lb.)
[P] 3” Pintle Eye - Channel-mount (21,000 lb.)

Axle Options
[52BS] (2) 5,200# (Dexter) Electric (Spring)
[52SS] (2) 5,200# (Dexter) Surge Hydraulic Drum [Surge Coupler] (Spring)

Tail Options
[S] Split Gate
[T] Split / Spreader Gate

Color Options
[K] Black Powder Coat
[0] Primer + Black Powder Coat
[1] Primer + Red Powder Coat
[3] Primer + White Powder Coat
[5] Primer + Tractor Orange Powder Coat
[6] Primer + Grey Powder Coat
[8] Primer + Desert Tan Powder Coat
[G] Grey Powder Coat
[N] Tractor Orange Powder Coat
[R] Red Powder Coat
[T] Desert Tan Powder Coat
[W] White Powder Coat
[Z] No Paint No Primer

Other Options
[-DR01] 1 Pair D-Rings
[-JAB1] Upgrade to (1) - Single BULLDOG 10k Jack
[-NTBX] No Tarp Mounting Brackets
[-RS01] Rear Support Stands
[0] Cold Weather Wiring Harness (7-Way RV)
[1] Upgrade to 235/80 R16 on 52k Axles
[3] Upgrade to Single 10k Jack (Bumper Pull)
[5] Solar Battery Charger
[C] 12”oc Crossmembers
[E] Power Up/Down & Gravity Down Upgrade
[M] Mount Only for Spare Tire
[P] Tarp kit (Pull Bar) 6 x 14ft
[R] Ramps w 4 D-Rings
[T] Spare Tire and Mount (Bumper Pull)

Parts Guide

Model Part Description Category Part Number
D3 Reflector Tape, Conspicuity R&W BODY 170237
D3 Coupler, 2-5/16” A-Frame Bulldog COUPLER 140218
D3 Fender Tandem Steel DP FENDER 160604
D3 Bracket Weld-on 5/16” Safety Chain HARDWARE 180410
D3 Cylinder 5”x30”x2” - D6& & W/O scis
(Without Scissor) 		HYDRAULIC 190206
D3 Pump Dual Action KTI w/3 qt Reserv HYDRAULIC 190605
D3 Pump Dual Action KTI w/Remote HYDRAULIC 190601
D3 Pump Tripleæ Action KTI w/Remote
(POWER UP/DOWN & GRAVITY DOWN OPTION) 		HYDRAULIC 190604
D3 Toolboxæ BP Dump w/Holes
(Bumper Pull) 		HYDRAULIC 160301
D3 Jack, 7K Dropleg Square Topwind
(Bumper pull) 		JACK 140101
D3 Light Kit LED - D6 D7 LIGHTING 170505
D3 Bolt, Equalizer, 7/8”x4.75” Slipper 7K
(with 5.2k axles) 		SUSPENSION 120119
D3 Bolt, Hanger 9/16x3.5” Slipper 7K
(with 5.2k axles) 		SUSPENSION 120118
D3 Equalizer 7Kæ QRG (12”)
(5200 lb axles) 		SUSPENSION 120216
D3 Hanger Center 7K Slipper
(5200 lb axles) 		SUSPENSION 120115
D3 Hanger Front 7K Slipper
(5200 lb axles) 		SUSPENSION 120116
D3 Hanger Rear 7K Slipper
(5200 lb axles) 		SUSPENSION 120117
D3 Lock Nut for 7K Eq Bolt 7/8”
(with 5.2k axles) 		SUSPENSION 120218
D3 Lock Nut Stover 9/16”-18 SUSPENSION 180152
D3 Spring Slipper 6 leaf 4000# 7/8K SUSPENSION 120102
D3 U-Bolt Kit 3” Rd. for 5.2-7K
(5200 lb axles) 		SUSPENSION 120301
D3 U-Bolt Kit 3.5” Rd. for 8K SUSPENSION 120302
D3 Tarp Kit 72in. x 14ft. Buyers TARP 160563
D3 225/75R15 Radial Tires TIRE 130107
D3 Tire&Whl 225/75R15 6 on 5.5” white spk TIRES & WHEELS 130224

Parts Guide Disclaimer: Parts can change based on the options, production date, and production location of the trailer. If there is any doubt about parts fitment please contact a PJ Parts representative with the VIN of the trailer in question.
