83" Tandem Axle Channel Utility (UL)

Available Lengths

  • 10’
  • 12’
  • 14’
  • 16’
  • 18’
  • 20’
  • 22’

Dare to Compare

Dare To Compare

Financing

Financing

Ready Rail® Options


Standard Features

  • 7,000 G.V.W.R.
  • 3,500 x 2 G.A.W.R.
  • 2” Ball Bulldog Coupler
  • Safety Chains
  • 1 - Bulldog Pipe Mount Swivel Jack (5,000 lb.)
  • (2) 3,500# (Dexter) One Electric (Spring)
  • 4 Leaf Double-eye Spring Suspension
  • 4 - NEW 15” White Spoke Wheels
  • 4 - ST205/75R15 Radial Tires (1,820 lb)
  • Stake Pockets
  • 9” x 33” Treadplate Removable Alum Fenders
  • 4” Channel Frame & Tongue
  • 2 1/2” x 2 1/2” x 3/16” Angle Crossmembers
  • 2” x 2” Removable Side Rail
  • 2” x 2” Top Rail
  • 2” Treated Canadian Spruce Pine Fir Deck
  • 83” Wide Deck
  • Flushmount 6” Oval Lifetime LED Tail Lights
  • Sealed Wire Harness
  • Sand Blasted, Acid Washed, Powder Coated
  • 5 year Dexter Axle Warranty

Notes:
*** Must have 3,500 lb axles with Tilt Deck Tail option. ***
*** 5,200 lb axles come with 16” on center cross members. ***
*** Drop and Torsion Axle options will come with Steel Fender. ***
*** Trailer will have 80” Frame with Drop & Torsion Axles. ***
Bumper Pull Tongue Length (3’ 7”).
***Dovetail Option - 14’ And Shorter Get a 16” Dove And 16’ And Longer Get a 2’ Dove***

Options

Default options, those included in the base model, are marked by a check .

Coupler Options

[2] BP 2” A-Frame
[A] BP 2 5/16” A-Frame
[D] BP 2” Adjustable
[J] BP 2 5/16” Adjustable
[M] BP 2” Atwood Style A-Frame Coupler
[N] BP 2 5/16” Atwood Style A-Frame Coupler
[P] 3” Pintle Eye - Channel-mount

Axle Options

[32CD] (2) 3,500# (Dexter) One Electric (Drop Axle)
[32CS] (2) 3,500# (Dexter) One Electric (Spring)
[32CT] (2) 3,500# (Dexter) One Electric (Torsion)
[32DS] (2) 3,500# (Dexter) Idler (Spring)
[32ED] (2) 3,500# (Dexter) Electric (Drop Axle)
[32ES] (2) 3,500# (Dexter) Electric (Spring)
[32ET] (2) 3,500# (Dexter) Electric (Torsion)
[32GS] (2) 3,500# (Dexter) Elec/Hyd Drum (1,000 PSI Pump) (Spring)
[32MS] (2) 3,500# (Dexter) Surge Hyd. Drum [Surge Coupler] 1 Brake 1 Drag (Spring)
[32SS] (2) 3,500# (Dexter) Surge Hydraulic Drum [Surge Coupler] (Spring)
[52CS] (2) 5,200# (Dexter) One Electric (Spring)
[52ES] (2) 5,200# (Dexter) Electric (Spring)
[52SS] (2) 5,200# (Dexter) Surge Hydraulic Drum [Surge Coupler] (Spring)

Tail Options

[S] Straight Deck
[2] Dovetail w/ 5’ Slide-in Ramps
[3] 4’ Dovetail w/ Split Gate
[A] Dovetail w/ 2 Fold-up Ramps
[B] Dovetail w/ 4’ Fold-up Gate
[C] Straight Deck w/ 2 Fold-up Ramps
[D] 4’ Dovetail w/ 2 Fold-up Ramps
[E] 4’ Dovetail w/ 4’ Fold-up Gate
[F] Straight Deck with Fold In Gate
[G] Straight Deck w/ 4’ Fold-up Gate
[H] Straight Deck w/ 4’ Heavy Duty Fold-up Gate
[J] Dovetail w/ 4’ Heavy Duty Fold-up Gate
[K] Straight Deck w/ Bi-Fold Gate
[M] Dovetail w/ Bi-Fold Gate
[P] Dovetail w/ Split Gate
[Q] Straight Deck w/ Split Heavy Duty Gate
[R] Straight Deck w/ 5’ Slide-in Ramps
[T] Tilt Deck (Single Axle - ATV Use Only)
[W] Straight Deck w/ 3’ Fold-up Gate
[X] Dovetail w/ Split Heavy Duty Gate
[Y] Dovetail w/ 3’ Fold-up Gate

Color Options

[K] Black Powder Coat
[G] Grey Powder Coat
[J] Tractor Green Powder Coat
[N] Tractor Orange Powder Coat
[R] Red Powder Coat
[T] Desert Tan Powder Coat
[W] White Powder Coat

Other Options

[-BWFL] Blackwood Classic Lumber Full Deck
[-BWOT] Blackwood Classic Lumber Outer Deck
[-DL01] 1 Pair of Flushmount D-Rings on Wood Floor
[-DR01] 1 Pair D-Rings
[-GT10] Ramp Gate Transition Lip
[-TB01] Front Toolbox (with 7k Jack)
[-TD01] 1 Set of Cargo Tie Down (2) Loops
[-TD05] 5 Sets of Cargo Tie Down (10) Loops
[-WR01] Trimmer Rack Kit
[2] 2ft Expanded Metal Sides
[3] Upgrade to 225/75 R15 on 3.5k Axles
[4] 4ft Expanded Metal Sides
[5] Regular Sides w/Solid Metal
[6] Regular Sides w/Expanded Metal
[7] Upgrade to 7k Jack
[8] 2 Stake Pockets In Front of Trailer
[A] Side Mount ATV Ramps (12ft or Longer)
[C] Landscape Toolbox (Must Have Siderails)
[E] Side Bi-Fold Gate
[F] Steel Diamond Plate Fenders
[G] 4ft Side Gate (14ft or longer)
[J] LED Light Upgrade Clearance/Marker
[K] 4 ft. Side Rails (No Mesh)
[M] Expanded Metal Floor
[P] 2” Pipetop Removable Siderails
[Q] Rubrail
[S] 11ga DP Steel Floor w/4 D-Rings & 16”oc
[T] Spare Tire Mount
[U] Rear Trailer Support Jacks
[V] Spare Tire and Mount
[W] 12” oc Crossmembers
[X] 16”oc Crossmembers
[Z] 22” Solid Metal Sides w/ 2” pipe-top

Parts Guide

Model Part Description Category Part Number
UL 3,500# Electric / Spring AXLE 110162
UL 3,500# Idler / Spring AXLE 110163
UL LH Side Rail for U8 w/ ATV Ramps BODY 160656
UL RH Side Rail for U8 w/ ATV Ramps BODY 160655
UL Coupler, 2” A-Frame Bulldog COUPLER 140200
UL Gate 1ft side for U8 83in Black GATE 160266
UL Gate Assy Heavy Duty U8 83” Black GATE 160268
UL Mounting kit for U6, U7 or U8 gate GATE 160267
UL Bracket Weld-on 5/16” Safety Chain HARDWARE 180410
UL Jack, 5K Pipe Mount 15” Topwind
(Option)
JACK 140100
UL Tailight, 6” Oval, Red Sealed LIGHTING 170205
UL Ramp 3” Chnl 13”x60” C5&C6 -Semin
(Slide-in Ramps)
RAMPS 160273
UL Equalizer 3.5K Triangle Double Eye
(3500 lb axles)
SUSPENSION 120217
UL Hanger 2-Axle 3.5K, Frt, Ctr, Rear SUSPENSION 120145
UL Hanger Bolt 3”x9/16” - 18
(with 3.5k axles)
SUSPENSION 120141
UL Lock Nut Stover 9/16”-18 SUSPENSION 180152
UL Nut 1/2” ID -for 2-3/8” U-bolt SUSPENSION 180079
UL Spring Dbl.eye 4 leaf 1750#
(3500 lb axles)
SUSPENSION 120100
UL U-bolt Plate, 2-3/8” SUSPENSION 120313
UL U-Bolt, 2-3/8” x 5-1/2” x 1/2”-20 SUSPENSION 120314
UL 15” white spoke Wheels w/ 5 on 5”
(3500 lb axle)
TIRES & WHEELS 130300
UL Tire&Whl 205/75R15 on 550 white spk
(3500 lb axle)
TIRES & WHEELS 130200

Parts Guide Disclaimer: Parts can change based on the options, production date, and production location of the trailer. If there is any doubt about parts fitment please contact a PJ Parts representative with the VIN of the trailer in question.
